High Elongation Aluminium Alloy Sheet DIN 1623 EN 10130 5083 5086
  • High Elongation Aluminium Alloy Sheet DIN 1623 EN 10130 5083 5086
High Elongation Aluminium Alloy Sheet DIN 1623 EN 10130 5083 5086

High Elongation Aluminium Alloy Sheet DIN 1623 EN 10130 5083 5086

Place of Origin China
Brand Name Aluminum Corporation of China
Model Number 1000，2000，3000，4000，5000，6000，7000
Product Details
Temper:
O, H14, H16, H18, H22, H24, H26, Etc.
Formability:
Excellent
Elongation:
≥8%
Tensile Strength:
≥160Mpa
Density:
2.7g/cm3
Length:
1000-6000mm
Material:
Aluminium Alloy
Thickness:
0.5-4mm
Highlight:

High Elongation Aluminium Alloy Sheet

,

DIN 1623 Aluminium Alloy Sheet

,

Aluminium 5086 Sheet

Payment & Shipping Terms
Minimum Order Quantity
1ton
Price
1000 - 19999 kilograms $2-2.32
Packaging Details
Customer Requirement
Delivery Time
3-25days according stock
Payment Terms
L/C, T/T, Western Union
Supply Ability
2000 Ton/Tons per Month
Product Description

DIN 1623 EN 10130 High Elongation Aluminium Alloy Sheet 5083 5086 Aluminum Sheet

Product Description:

Aluminium Alloy Sheet is a type of metal sheet made from aluminium alloy. It is known for its high purity of up to 99.99%, excellent formability, and a variety of tempers, including O, H14, H16, H18, H22, H24, and H26. This metal sheet is mainly available in the form of flat sheets, and it has an elongation of more than 8%. It is widely used in various manufacturing processes, such as Aluminium Alloy Sheet Coil and Aluminium Alloy Sheet Plate manufacturing.

High Elongation Aluminium Alloy Sheet DIN 1623 EN 10130 5083 5086 0 High Elongation Aluminium Alloy Sheet DIN 1623 EN 10130 5083 5086 1
High Elongation Aluminium Alloy Sheet DIN 1623 EN 10130 5083 5086 2 High Elongation Aluminium Alloy Sheet DIN 1623 EN 10130 5083 5086 3



Specification of Aluminium Sheet
Alloy No.
Thickness(mm)
Width(mm)
Temper

A1050,A1060, A1070,A1100,A1235,A1245
0.2-3.0
20-1900
O,H12,H22,H14,H24,H16,H26,H18
4.0-12.0
1000-1900
H111,H112
A3003,A3004,A3105
0.2-4.0
20-1900
O,H12,H22,H14,H24,H16,H26,H18
4.0-12.0
1000-1900
H111,H112
A5052,A5083,A5754,A5005
0.2-4.0
20-1900
O,H12,H22,H14,H24,H16,H26,H18
4.0-12.0
1000-1900
H111,H112
A6061,A6082,A6063
0.8-3.0
20-1900
O
A8011,A1145,A1235
0.005-0.2
20-1700
O,,H18,H24
ID
76mm,152mm,200mm,300mm,505mm
Packing : Export wooden pallets, wooden case
Standards:ASTM-B209. EN573-1, GB/T3880.1-2006
Quality of material: totally free from defects like white rust, oil patches, roll marks, edge damage,
camber, dents, holes, break lines, scratches and free from coil set
MOQ
4 tons
Payment term:
TT,L/C,D/P, West Union
Delivery Time
Future goods:20-30 Work days,Ready Stock:7-10 days.
Kind attention : Specifications can be customized as the customer's requirements.

 Applications:

Aluminium Alloy Sheet, manufactured by Aluminum Corporation of China, is a highly versatile product, available in various models, such as 1000, 2000, 3000, 4000, 5000 and 6000. It has excellent properties, which make it suitable for a variety of applications. Its elongation is ≥8%, and its length ranges from 1000 to 6000mm. It is made of aluminium alloy, and has a density of 2.7g/cm3. It is available in a flat sheet shape.
Aluminium Alloy Sheet is widely used in the manufacturing of construction materials, automotive parts, aerospace components, and many other industrial applications. It provides a durable and strong finish, and is highly resistant to corrosion, making it an ideal choice for these industries. It is also used in the production of furniture and decorative items, as its light weight makes it easy to transport and install.
Aluminium Alloy Sheet has become increasingly popular in the manufacturing industry for its excellent properties. It is corrosion-resistant, light-weight, and strong, making it a preferred choice for many companies. It is also cost-effective and can be easily fabricated into a variety of shapes, which makes it a great choice for any application.

Standard
JIS G3141,DIN1623,EN10130
Thickness
0.15-6.0mm(Aluminum sheet) 6.0-25.0mm(Aluminum plate)
Temper
O, H12, H22, H32, H14, H24, H34, H16, H26, H36, H18, H28, H38, H19, H25, H27,H111, H112,H241, H332, etc.
Surface Treatment
Mill Finished, Anodized, Embossed, PVC Coated etc
Alloy
Application field



1xxx
1050
Insulation, food industry, decoration, lamp, traffic signs etc.
1060
Fan blade, Lamps and lanterns, Capacitor shell, Auto parts, Welding parts.
1070
Capacitor, Rear panel of vehicle refrigerator, charging point, heat sink etc
1100
Cooker, building material, printing, heat exchanger, bottle cap etc

2xxx
2A12
2024
Aircraft structures, rivets, aviation, machinery, missile components, the card wheel hub, propeller components, aerospace parts,car parts and various other structural parts.


3xxx
3003 3004
3005 3105
Aluminum curtain wall panel, aluminum Ceiling, Electric cooker bottom, TV LCD backboard, storage tank, curtain wall, building construction panel heat sink, billboard. Industrial floor, air conditioning, refrigerators radiators, Make-up board, Prefabricated house etc.






5xxx
5052
Marine and transportation material, railway carriage's inner and outer cabinet, oil and chemical industry storage device,equipment and medical device panel etc.
5005
Marine applications, bodies of boats, buses, trucks and trailer. Curtain wall panel.
5086
Ship board, deck, bottom and edge panel etc.
5083
Tanker, oil storage tank, drilling platform, ship board, deck, bottom, welded parts and edge panel, railway carriage 's board,automotive and aircraft panel, cooling device and automotive molding etc.
5182
5454
5754
Tanker body, marine facilities, pressure container, transportation etc.


6xxx
6061
6083
6082
Railway inside and outside parts, board and bed plate. Industry molding
Highly stressed applications includes Roofing construction,transportation, and marine as well as mould.

6063
Auto parts, architectural fabrication, window and door frames, aluminum furniture, electronic components as well as various consumer durable products.


7xxx
7005
Truss, rod/bar and the container in transportation vehicles; Large-sized heat ex changers.



7050
Molding (bottles) mode, ultrasonic plastic welding mold, golf head, shoe mold, paper and plastic molding, foam molding, lost wax mold, templates, fixtures, machinery and equipment.
7075
Aerospace industry, military industry, electronic etc.





High Elongation Aluminium Alloy Sheet DIN 1623 EN 10130 5083 5086 4

Support and Services:

Technical support and service for Aluminium Alloy Sheet:

  • Provide technical guidance on product selection and installation.
  • Help customers solve problems encountered in the use of products.
  • Provide professional training for users.
  • Provide after-sales service and maintenance.
  • Provide product tracking and feedback service.
  • Provide product literature and product related information.


Packing and Shipping:

Packaging and Shipping for Aluminium Alloy Sheet:

  • The Aluminium Alloy Sheet will be securely and ely packed in strong cardboard boxes or wooden crates.
  • The product will be shipped within the specified time frame.
  • The method of shipping will depend on the destination and the size of the order.
  • The product will be shipped with a tracking number for tracking and tracing purposes.
 High Elongation Aluminium Alloy Sheet DIN 1623 EN 10130 5083 5086 5

FAQ:

Q1: What is Aluminum Corporation of China?
A1: Aluminum Corporation of China Limited (known as Chalco), is a Chinese company listed in Hong Kong SAR and in New York. It is the world's second-largest alumina producer and the third-largest primary aluminum producer.
Q2: What are the model numbers of Aluminum Alloy Sheet?
A2: Aluminum Alloy Sheet of Aluminum Corporation of China has model numbers 1000, 2000, 3000, 4000, 5000, 6000, and 7000.
Q3: Where is Aluminum Alloy Sheet of Aluminum Corporation of China made?
A3: Aluminum Alloy Sheet of Aluminum Corporation of China is made in China.
Q4: What are the common applications of Aluminum Alloy Sheet?
A4: Aluminum Alloy Sheet of Aluminum Corporation of China can be used for many applications such as in automobile and aircraft structures, frames, ships, and boats, and in various industrial and consumer products.
Q5: Does Aluminum Alloy Sheet of Aluminum Corporation of China have any certifications?
A5: Yes, Aluminum Alloy Sheet of Aluminum Corporation of China is certified by international organizations such as ISO, CE, SGS, and ASTM.
