Aluminium Alloy Sheet
>
|
| Place of Origin | China |
| Brand Name | Aluminum Corporation of China |
| Model Number | 1000，2000，3000，4000，5000，6000，7000 |
Aluminium Alloy Sheet is a high-quality material manufactured as flat sheets and coils by a reliable aluminium alloy sheet coil supplier. The sheets and coils come in various widths and lengths, ranging from 1000 to 2000mm in width and 1000 to 6000mm in length. The sheets and coils also have excellent properties, such as an elongation of 8% and tensile strength of 160Mpa or higher. This makes them ideal for a wide range of applications, from automotive and aerospace to construction and manufacturing. Moreover, the aluminium alloy sheet coils are highly durable and resistant to corrosion, making them a great choice for a long-lasting product.
|
|
|
|
|
Specification of Aluminium Sheet
|
||||
|
Alloy No.
|
Thickness(mm)
|
Width(mm)
|
Temper
|
|
|
|
||||
|
A1050,A1060, A1070,A1100,A1235,A1245
|
0.2-3.0
|
20-1900
|
O,H12,H22,H14,H24,H16,H26,H18
|
|
|
4.0-12.0
|
1000-1900
|
H111,H112
|
||
|
A3003,A3004,A3105
|
0.2-4.0
|
20-1900
|
O,H12,H22,H14,H24,H16,H26,H18
|
|
|
4.0-12.0
|
1000-1900
|
H111,H112
|
||
|
A5052,A5083,A5754,A5005
|
0.2-4.0
|
20-1900
|
O,H12,H22,H14,H24,H16,H26,H18
|
|
|
4.0-12.0
|
1000-1900
|
H111,H112
|
||
|
A6061,A6082,A6063
|
0.8-3.0
|
20-1900
|
O
|
|
|
A8011,A1145,A1235
|
0.005-0.2
|
20-1700
|
O,,H18,H24
|
|
|
ID
|
76mm,152mm,200mm,300mm,505mm
|
|||
|
Packing : Export wooden pallets, wooden case
|
||||
|
Standards:ASTM-B209. EN573-1, GB/T3880.1-2006
|
||||
|
Quality of material: totally free from defects like white rust, oil patches, roll marks, edge damage,
camber, dents, holes, break lines, scratches and free from coil set |
||||
|
MOQ
|
4 tons
|
|||
|
Payment term:
|
TT,L/C,D/P, West Union
|
|||
|
Delivery Time
|
Future goods:20-30 Work days,Ready Stock:7-10 days.
|
|||
|
Kind attention : Specifications can be customized as the customer's requirements.
|
||||
Aluminium Alloy Sheet is a type of metal product manufactured by Aluminum Corporation of China. It is made from alloys of aluminum and other metals, such as copper, magnesium, manganese, silicon, and zinc. It is available in different models, such as 1000, 2000, 3000, 4000, 5000, 6000, and 7000. The shape of the sheet is flat and its width ranges from 1000 to 2000mm. The temper can be O, H14, H16, H18, H22, H24, H26, and etc. The material is aluminum alloy and the elongation is ≥8%.
The use of Aluminium Alloy Sheet is highly versatile. It is widely used in manufacturing applications, such as for making cars, ships, airplanes, and other transportation vehicles. It is also used in construction projects, such as for constructing bridges, buildings, and other structures. Moreover, it is used in the production of aluminium alloy plates, which are used in a variety of industries, including electronics, automotive, and building materials.
Aluminium Alloy Sheet manufacturing is an important process in the production of aluminium alloy plates. The process involves several steps, such as cutting, welding, and drilling. It is important to ensure that the sheets are cut, welded, and drilled properly, as this will determine the quality and performance of the aluminium alloy plates. Moreover, the process also requires special tools and machinery, such as saws, drills, and grinders.
Aluminium Alloy Sheet is highly durable and resistant to corrosion. This makes it ideal for use in a wide range of applications. It is also light in weight and has good thermal conductivity. As such, it is used in the production of many products, such as heat sinks, refrigerator liners, and solar panels. In addition, it is also used in the manufacture of consumer goods, such as cookware, utensils, and cans.
Aluminium Alloy Sheet is an essential product for many industries. It is used in the manufacturing of many products, such as automobiles, aircraft, ships, and buildings. It is also used in the production of aluminium alloy plates, which are used in many industries, including electronics, automotive, and building materials. Thus, the use of Aluminium Alloy Sheet is essential for the production of many products.
|
Standard
|
JIS G3141,DIN1623,EN10130
|
|
|
Thickness
|
0.15-6.0mm(Aluminum sheet) 6.0-25.0mm(Aluminum plate)
|
|
|
Temper
|
O, H12, H22, H32, H14, H24, H34, H16, H26, H36, H18, H28, H38, H19, H25, H27,H111, H112,H241, H332, etc.
|
|
|
Surface Treatment
|
Mill Finished, Anodized, Embossed, PVC Coated etc
|
|
|
Alloy
|
Application field
|
|
|
1xxx
|
1050
|
Insulation, food industry, decoration, lamp, traffic signs etc.
|
|
1060
|
Fan blade, Lamps and lanterns, Capacitor shell, Auto parts, Welding parts.
|
|
|
1070
|
Capacitor, Rear panel of vehicle refrigerator, charging point, heat sink etc
|
|
|
1100
|
Cooker, building material, printing, heat exchanger, bottle cap etc
|
|
|
2xxx
|
2A12
2024
|
Aircraft structures, rivets, aviation, machinery, missile components, the card wheel hub, propeller components, aerospace parts,car parts and various other structural parts.
|
|
3xxx
|
3003 3004
3005 3105 |
Aluminum curtain wall panel, aluminum Ceiling, Electric cooker bottom, TV LCD backboard, storage tank, curtain wall, building construction panel heat sink, billboard. Industrial floor, air conditioning, refrigerators radiators, Make-up board, Prefabricated house etc.
|
|
5xxx
|
5052
|
Marine and transportation material, railway carriage's inner and outer cabinet, oil and chemical industry storage device,equipment and medical device panel etc.
|
|
5005
|
Marine applications, bodies of boats, buses, trucks and trailer. Curtain wall panel.
|
|
|
5086
|
Ship board, deck, bottom and edge panel etc.
|
|
|
5083
|
Tanker, oil storage tank, drilling platform, ship board, deck, bottom, welded parts and edge panel, railway carriage 's board,automotive and aircraft panel, cooling device and automotive molding etc.
|
|
|
5182
|
||
|
5454
|
||
|
5754
|
Tanker body, marine facilities, pressure container, transportation etc.
|
|
|
6xxx
|
6061
6083 6082 |
Railway inside and outside parts, board and bed plate. Industry molding
Highly stressed applications includes Roofing construction,transportation, and marine as well as mould. |
|
|
Auto parts, architectural fabrication, window and door frames, aluminum furniture, electronic components as well as various consumer durable products.
|
|
|
7xxx
|
7005
|
Truss, rod/bar and the container in transportation vehicles; Large-sized heat ex changers.
|
|
7050
|
Molding (bottles) mode, ultrasonic plastic welding mold, golf head, shoe mold, paper and plastic molding, foam molding, lost wax mold, templates, fixtures, machinery and equipment.
|
|
|
7075
|
Aerospace industry, military industry, electronic etc.
|
|
The technical support and services for Aluminium Alloy Sheet include:
Aluminium Alloy Sheet packaging and shipping:
The aluminum alloy sheet is packaged with moisture-proof and rust-proof paper or film. It is then placed in a wooden box or metal frame for protection during transportation, and finally loaded onto the transportation vehicle.
